Welcome! ZZJG VALVE Factory Can Offer High Quality Line Blind Valves And Goggle Valves.
Sleeve plug valve has fixed sleeve no displacement with plug valve body. The application of sleeve plug valve is gas-solid & liquid-solid with high washing ability; acid production, alkali production, petroleum, and chemical industries.
Diameter: DN15~1000mm NPS1/2"~40"
Pressure: PN0.6~25MPa Class150~1500
Materials: Ductile Cast Iron, Carbon Steel, Stainless Steel, Alloy Steel, etc
Operation: Manual, Worm Gear, Hydraulic, Electric, Pneumatic
Standard: ANSI, API, DIN, EAC, JIS, CE, ISO, EN, GB.
No body cavities, self-cleaning design on sealing surfaces. Antistatic & fireproof design for safety.
PTFE sleeve material, self-lubricated, small operating torque.Compensable sealing pressure for high quality sealing without leakage.
Top entry design, easy for online installation & maintenance. Bidirectional seals, no limitation on the flow direction.
Full-bore or necked-type plug valve can be chosen, Jacketed design can be chosen.
The professional 3D software for structural analysis, material selection and process planning to virtually simulate the reliability of materials under different temperatures, mediums andpressures, and finally validate them through finite element analysis to provide customers with safe and reliable products.
From raw materials to production, sealing performance testing, strength testing, functional testing, to surface quality testing and packaging and shipping, the whole process is strictly in accordance with API standards and support third-party independent organizations to test and certify our products.
